Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-51
Example 1
digio.trigger[3].stimulus = 0
Clear the trigger stimulus of digital I/O line 3.
Example 2
digio.trigger[3].stimulus = smua.trigger.SOURCE_COMPLETE_EVENT_ID
Set the trigger stimulus of digital I/O line 3 to be the source complete event.
Also see
digio.trigger[N].assert() (on page 11-44)
digio.trigger[N].clear() (on page 11-44)
digio.trigger[N].reset() (on page 11-49)
digio.trigger[N].wait()
This function waits for a trigger.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
triggered = digio.trigger[N].wait(timeout)
triggered
The value is true if a trigger is detected, or false if no triggers are detected during
the timeout period
N
Digital I/O trigger line (1 to 14)
timeout
Timeout in seconds
Details
This function pauses for up to timeout seconds for an input trigger. If one or more trigger events are
detected since the last time digio.trigger[N].wait() or digio.trigger[N].clear() was
called, this function returns a value immediately. After waiting for a trigger with this function, the event
detector is automatically reset and ready to detect the next trigger. This is true regardless of the
number of events detected.
Example
triggered = digio.trigger[4].wait(3)
print(triggered)
Waits up to three seconds for a trigger to be
detected on trigger line 4, then outputs the
results.
Output if no trigger is detected:
false
Output if a trigger is detected:
true
Also see
digio.trigger[N].clear() (on page 11-44)
