Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-218 2601B-PULSE-901-01A April 2020
smua.pulser.protect.tripped
This attribute indicates if the protection circuit was tripped.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (R)
Yes
Instrument reset
SMU reset
None
Not applicable
Usage
tripped = smua.pulser.protect.tripped
tripped
The voltage protection status:
▪ true: The protection circuit was tripped
▪ false: The protection circuit was not tripped
Details
When the pulser is enabled, this attribute indicates if the protection circuit was tripped. When the
protection circuit is tripped, the output is shorted and turned off.
The following events can trip the protection circuit:
• A voltage greater than smua.pulser.protect.sensev was detected on the sense terminals.
• A voltage greater than smua.pulser.protect.sourcev was detected on the force terminals.
• The maximum pulse width was exceeded during trigger model operation.
• The maximum duty cycle was exceeded during trigger model operation.
• If the SMU cannot keep up with the pulse rate.
• If the SMU cannot keep up with the measurement rate.
The status is reset to false when the pulser is disabled or when the output is turned on.
Example
print(smua.pulser.protect.tripped)
Determine if the protection circuit was tripped.
Also see
smua.pulser.protect.sensev (on page 11-216)
smua.pulser.protect.sourcev (on page 11-217)
