Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-220 2601B-PULSE-901-01A April 2020
smua.pulser.rangeY
This attribute sets the source and measure ranges when the pulser is enabled.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
SMU reset
Recall setup
Saved setup
Current: 10 A
Voltage: 10 V
Usage
range = smua.pulser.rangei
range = smua.pulser.rangev
smua.pulser.rangei = range
smua.pulser.rangev = range
range
The source and measure range
Details
When you set a value for the range, the 2601B-PULSE automatically sets the range as appropriate
for the specified value.
This attribute setting affects the settings that are allowed for the smua.pulser.protect.sensev
attribute, which must be between 5 percent and 200 percent of the voltage range.
The following table lists the pulser voltage and current ranges.
Voltage range
Source
Measure
5 V
Not applicable
5.1 V
10 V
Not applicable
10.2 V
Current ranges
1 A
±1.01 A
±1.02 A
5 A
±5.05 A
±5.1 A
10 A
±10.1 A
±10.2 A
250 mA (DC bias)
±250 mA
Selected pulse measure range
The 2601B-PULSE can sustain a measurement speed of 33,000, as determined by:
(Pulse rate per second) + (Measurements per second  Filter count) < 33000
If this rate is exceeded, the instrument may not be able to sustain the sweep.
The settings for this attribute are ignored if the pulser is disabled.
Example
smua.pulser.rangei = 1
Set the pulser current range to 1 A.
Also see
smua.pulser.protect.sensev (on page 11-216)
