Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-240 2601B-PULSE-901-01A April 2020
Example
smua.trigger.arm.stimulus = trigger.timer[1].EVENT_ID
An event on trigger timer 1 causes the arm event detector to enter the detected state.
Also see
Triggering (on page 6-1)
smua.trigger.ARMED_EVENT_ID
This constant contains the number of the armed event.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Constant
Yes
Usage
eventID = smua.trigger.ARMED_EVENT_ID
eventID
The armed event number
Details
Set the stimulus of any trigger object to the value of this constant to have the trigger object respond to
armed events from this SMU.
Example
trigger.timer[1].stimulus = smua.trigger.ARMED_EVENT_ID
Trigger timer when the SMU passes through the arm layer.
Also see
Triggering (on page 6-1)
smua.trigger.autoclear
This attribute turns automatic clearing of the event detectors on or off.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Not saved
0 (smua.DISABLE)
Usage
autoClear = smua.trigger.autoclear
smua.trigger.autoclear = autoClear
autoClear
Auto clear setting; set to one of the following values:
▪ 0 or smua.DISABLE: Turns off automatic clearing of the event detectors
▪ 1 or smua.ENABLE: Turns on automatic clearing of the event detectors
