Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-32 2601B-PULSE-901-01A April 2020
Example
printbuffer(1, 1, smua.nvbuffer1.sourceoutputstates)
Print the source output for the first
reading stored in dedicated
reading buffer 1.
Example output:
On
Also see
bufferVar.measurefunctions (on page 11-26)
bufferVar.measureranges (on page 11-27)
bufferVar.n (on page 11-28)
bufferVar.readings (on page 11-29)
bufferVar.sourcefunctions (on page 11-30)
bufferVar.sourceranges (on page 11-32)
bufferVar.sourcevalues (on page 11-33)
bufferVar.statuses (on page 11-34)
bufferVar.timestamps (on page 11-37)
Reading buffers (on page 5-1)
bufferVar.sourceranges
This attribute contains the source range that was used for readings stored in a specified reading buffer.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (R)
Yes
Clearing the buffer
See Details
Not applicable
Usage
sourcerange = bufferVar.sourceranges[N]
sourcerange
The source range used to acquire reading number N in the specified buffer
bufferVar
The reading buffer; can be a dynamically allocated buffer (user-defined), or a
dedicated reading buffer (such as smua.nvbuffer1)
N
The reading number (1 to bufferVar.n)
Details
The bufferVar.sourceranges buffer recall attribute is like an array (a Lua table) of full-scale
range values for the source range used when the measurement was made.
For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the
reading buffer is saved to nonvolatile memory.
Example 1
sourcerange = smua.nvbuffer1.sourceranges[1]
Store the source range that was used for the
first reading stored in dedicated reading
buffer 1.
