Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-274 2601B-PULSE-901-01A April 2020
Bit
Value
B0
Not used
B1
status.measurement.protection.SMUA
Set bit indicates one of the pulser protection circuits have tripped.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2 to B15
Not used
In addition to the above constants, measurementRegister can be set to the decimal value of the
bit to set.
Example 1
status.measurement.protection.enable = status.measurement.protection.SMUA
Uses the constant to set bit 1, the SMU A bit of the measurement event protection summary enable register.
Example 2
status.measurement.protection.enable = 2
Uses the decimal value to set bit 1, the SMU A bit of the measurement event protection summary
enable register.
Also see
Measurement event registers (on page 15-7)
status.measurement.reading_overflow.*
This attribute contains the measurement event reading overflow summary register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
2 (All bits set)
Usage
measurementRegister = status.measurement.reading_overflow.condition
measurementRegister = status.measurement.reading_overflow.enable
measurementRegister = status.measurement.reading_overflow.event
measurementRegister = status.measurement.reading_overflow.ntr
measurementRegister = status.measurement.reading_overflow.ptr
status.measurement.reading_overflow.enable = measurementRegister
status.measurement.reading_overflow.ntr = measurementRegister
status.measurement.reading_overflow.ptr = measurementRegister
measurementRegister
The status of the measurement reading overflow summary
register; a zero (0) indicates no bits set (also send 0 to clear all
bits); other values indicate various bit settings
