Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 13: Calibration
2601B-PULSE-901-01A April 2020 13-23
2601B-PULSE adjustment steps
Function
1
Adjustment steps
2
Adjustment points
4
Sense mode
Voltage source
and measure
100 mV
±1e-30, ±90 mV
smua.SENSE_LOCAL
100 mV
±1e-30, ±90 mV
smua.SENSE_REMOTE
1 V
±1e-30, ±0.9 V
smua.SENSE_LOCAL
1 V
±1e-30, ±0.9 V
smua.SENSE_CALA
6 V
±1e-30, ±5.4 V
smua.SENSE_LOCAL
40 V
±1e-30, ±36 V
smua.SENSE_LOCAL
Current source
and measure
100 nA
±1e-30, ±90 nA
smua.SENSE_LOCAL
1 μA
±1e-30, ±0.9 μA
smua.SENSE_LOCAL
10 μA
±1e-30, ±9 μA
smua.SENSE_LOCAL
100 μA
±1e-30, ±90 μA
smua.SENSE_LOCAL
1 mA
±1e-30, ±0.9 mA
smua.SENSE_LOCAL
1 mA
±1e-30, ±0.9 mA
smua.SENSE_CALA
10 mA
±1e-30, ±9 mA
smua.SENSE_LOCAL
100 mA
±1e-30, ±90 mA
smua.SENSE_LOCAL
1 A
±1e-30, ±0.9 A
smua.SENSE_LOCAL
3 A
±1e-30, ±2.4 A
smua.SENSE_LOCAL
10 A
3
±1e-30, ±2.4 A
smua.SENSE_LOCAL
Pulser bias source
250 mA
±2.5, ±225 mA
smua.SENSE_REMOTE
Pulse source
and measure
1 A
5
±0.01, ±0.75 A
smua.SENSE_REMOTE
5 A
5
±0.01, ±4 A
smua.SENSE_REMOTE
10 A
±0.01, ±9 A
smua.SENSE_REMOTE
5 V
5
±0.01, ±4 V
smua.SENSE_REMOTE
10 V
5
±0.01, ±9 V
smua.SENSE_REMOTE
1. Adjust only the source for the CALA sense steps.
2. Steps must be performed in the order shown.
3. 10 A range for changing adjustment of range only and is not available for normal use.
4. Do not use actual 0 values for zero adjustment points. Send very small values such as ±1e-30. Adjustment
polarities must also be set as shown in the procedures.
5. The 1 A source, 1 A measure, and 1 V measure ranges use 75% for full scale. The 5 A source, 5 A measure,
and 5 V measure ranges use 80% for full scale.
Calibration and adjustment command quick reference
The following table summarizes remote calibration and adjustment commands. For a more complete
description of these commands, refer to the TSP command reference (on page 11-1).
