digio.trigger[N].stimulus
This attribute selects the event that causes a trigger to be asserted on the digital output line.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
Digital I/O trigger N reset
Recall setup
Not saved
0
Usage
triggerStimulus = digio.trigger[N].stimulus
digio.trigger[N].stimulus = triggerStimulus
triggerStimulus
The event identifier for the triggering event
N
Digital I/O trigger line (1 to 14)
Details
Set this attribute to zero (0) to disable the automatic trigger output.
Do not use this attribute to generate output triggers under script control. Use
digio.trigger[N].assert() instead.
The trigger stimulus for a digital I/O line may be set to one of the existing trigger event IDs described
in the following table.
Trigger event IDs*
Event ID
Event description
smua.trigger.SWEEPING_EVENT_ID
Occurs when the source-measure unit (SMU) transitions from
the idle state to the arm layer of the trigger model
smua.trigger.ARMED_EVENT_ID
Occurs when the SMU moves from the arm layer to the trigger
layer of the trigger model
smua.trigger.SOURCE_COMPLETE_EVENT_ID
Occurs when the SMU completes a source action
smua.trigger.MEASURE_COMPLETE_EVENT_ID
Occurs when the SMU completes a measurement action
smua.trigger.PULSE_COMPLETE_EVENT_ID
Occurs when the SMU completes a pulse
smua.trigger.SWEEP_COMPLETE_EVENT_ID
Occurs when the SMU completes a sweep
smua.trigger.IDLE_EVENT_ID
Occurs when the SMU returns to the idle state
digio.trigger[N].EVENT_ID
Occurs when an edge is detected on a digital I/O line
tsplink.trigger[N].EVENT_ID
Occurs when an edge is detected on a TSP-Link line
lan.trigger[N].EVENT_ID
Occurs when the appropriate LXI trigger packet is received on
LAN trigger object N
display.trigger.EVENT_ID
Occurs when the TRIG key on the front panel is pressed
trigger.EVENT_ID
Occurs when a *TRG command is received on the remote
interface
GPIB only: Occurs when a GET bus command is received
USB only: Occurs when a USBTMC TRIGGER message is
received
VXI-11 only: Occurs with the VXI-11 command
device_trigger; reference the VXI-11 standard for
additional details on the device trigger operation
trigger.blender[N].EVENT_ID
Occurs after a collection of events is detected
trigger.timer[N].EVENT_ID
Occurs when a delay expires
trigger.generator[N].EVENT_ID
Occurs when the trigger.generator[N].assert()
function is executed
* Use the name of the trigger event ID to set the stimulus value rather than the numeric value. Using the name makes the
code compatible for future upgrades (for example, if the numeric values change if enhancements are added to instrument).
