Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-198 2601B-PULSE-901-01A April 2020
smua.measure.delay
This attribute controls the measurement delay.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
SMU reset
Recall setup
Saved setup
0 (smua.DELAY_OFF)
Usage
mDelay = smua.measure.delay
smua.measure.delay = mDelay
mDelay
Set to the measurement delay value in seconds (for example, to specify an
additional 10 ms measurement delay, set the value to 0.010)
You can also set it to one of the following values:
▪ 0 or smua.DELAY_OFF: No delay
▪ -1 or smua.DELAY_AUTO: Automatic delay value
Details
This attribute allows for additional delay (settling time) before making a measurement. If you define
the value instead of using the automatic delay value, the delay you set is used regardless of the
range.
The smua.DELAY_AUTO setting causes a current range-dependent delay to be inserted when a
current measurement is requested. This happens when a current measurement command is
executed, when the measure action is being performed in a sweep, or after changing ranges during
an autoranged measurement.
If smua.measure.count is greater than 1, the measurement delay is only inserted before the first
measurement.
Example
smua.measure.delay = 0.010
Sets a 10 ms measurement delay.
Also see
Measure auto delay (on page 4-55)
reset() (on page 11-156)
smua.measure.count (on page 11-197)
smua.measure.delayfactor (on page 11-199)
smua.source.delay (on page 11-226)
smua.reset() (on page 11-222)
