Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-362 2601B-PULSE-901-01A April 2020
Details
The trigger.timer[N].reset() function resets the following attributes to their factory defaults:
▪ trigger.timer[N].count
▪ trigger.timer[N].delay
▪ trigger.timer[N].delaylist
▪ trigger.timer[N].passthrough
▪ trigger.timer[N].stimulus
It also clears trigger.timer[N].overrun.
Example
trigger.timer[1].reset()
Resets the attributes associated with timer 1 back to factory
default values.
Also see
trigger.timer[N].count (on page 11-357)
trigger.timer[N].delay (on page 11-358)
trigger.timer[N].delaylist (on page 11-359)
trigger.timer[N].overrun (on page 11-360)
trigger.timer[N].passthrough (on page 11-361)
trigger.timer[N].stimulus (on page 11-362)
trigger.timer[N].stimulus
This attribute specifies which event starts the timer.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
Recall setup
Trigger timer N reset
Not saved
0
Usage
eventID = trigger.timer[N].stimulus
trigger.timer[N].stimulus = eventID
eventID
The event that triggers the timer delay
N
Trigger timer number (1 to 8)
Details
The eventID parameter may be one of the trigger event IDs shown in the following table.
Trigger event IDs*
Event ID
Event description
smua.trigger.SWEEPING_EVENT_ID
Occurs when the source-measure unit (SMU) transitions
from the idle state to the arm layer of the trigger model
smua.trigger.ARMED_EVENT_ID
Occurs when the SMU moves from the arm layer to the
trigger layer of the trigger model
smua.trigger.SOURCE_COMPLETE_EVENT_ID
Occurs when the SMU completes a source action
