Section 1: Introduction Model 2601B-PULSE System SourceMeter Instrument Reference Manual
1-2 2601B-PULSE-901-01A April 2020
Customer documentation
The documentation for the 2601B-PULSE includes a Quick Start Guide and Reference Manual (this
document). The 2601B-PULSE Quick Start Guide is provided as a hard copy with the instrument. You
can also access it from tek.com/keithley as an Adobe Acrobat PDF file.
• Quick Start Guide: Provides unpacking instructions, describes basic connections, and reviews
basic operation information. If you are new to Keithley Instruments equipment, refer to the Quick
Start Guide to take the steps needed to unpack, set up, and verify operation.
• Reference Manual: Includes advanced operation topics and maintenance information.
Programmers looking for a command reference and users looking for an in-depth description of
the way the instrument works (including troubleshooting and optimization) should refer to the
Reference Manual.
Product software and drivers
Go to the Product Support web page (tek.com/product-support) to download drivers and software for
your instrument.
Available drivers and software include:
• KickStart Software: Enables quick test setup and data visualization when using one or
more instruments.
• Test Script Builder (TSB): This software provides an environment to develop a test program and
the ability to load the test program onto the instrument. Running a program loaded on the
instrument eliminates the need to send individual commands from the host computer to the
instrument when running a test. For more information, see Installing the TSB software (on page
10-30).
• IVI-COM Driver: An IVI instrument driver you can use to create your own test applications in
C/C++, VB.NET or C#. It can also be called from other languages that support calling a DLL or
ActiveX (COM) object. Refer to IVI Foundation (ivifoundation.org) for additional information.
• LabVIEW
â„¢
Software drivers: Drivers to communicate with National Instruments
LabVIEW Software.
• Keithley I/O layer: Manages the communications between Keithley instrument drivers and
software applications and the instrument itself. The I/O Layer handles differences in
communications required to support GPIB, serial, ethernet, and other communications buses so
that drivers and software applications do not need to handle the differences themselves.
To identify IP addresses of instruments that are connected to the local area network (LAN) and
support the VXI-11 discovery protocol, you can also use LXI Discovery Tool, available from the
Resources (lxistandard.org/Resources/Resources.aspx) page of the LXI Consortium website
(lxistandard.org).
