Section 10: Instrument programming Model 2601B-PULSE System SourceMeter Instrument Reference Manual
10-32 2601B-PULSE-901-01A April 2020
Figure 130: Example of the Test Script Builder workspace
Item
Description
1
Project navigator
2
Script editor; right-click to run the script that is displayed
3
Outline view
4
Programming interaction
5
Help; includes detailed information on using Test Script Builder
Project navigator
The project navigator consists of project folders and the script files (.tsp) created for each project.
Each project folder can have one or more script files.
To view the script files in a project folder, select the plus (+) symbol next to the project folder. To hide
the folder contents, select the minus (−) symbol next to the project folder.
You can download a TSP project to the instrument and run it, or you can run it from the
TSB interface.
