Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-235
smua.source.rangeY
This attribute contains the source range.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Saved setup
Voltage: 100e-3 (100 mV)
Current: 100e-9 (100 nA)
Usage
rangeValue = smua.source.rangeY
smua.source.rangeY = rangeValue
rangeValue
Set to the maximum expected voltage or current to be sourced
Y
SMU source function (v = voltage, i = current)
Details
This attribute contains a value that sets the source-measure unit (SMU) to a fixed range large enough
to source the value. When read, the attribute contains the range the instrument is presently on when
in autorange.
Assigning a value to this attribute sets the SMU to a fixed range large enough to source the assigned
value. The instrument selects the best range for sourcing a value of rangeValue.
Reading this attribute returns the positive full-scale value of the source range the SMU is currently
using. With source autoranging enabled, the output level controls the range. Querying the range after
the level is set returns the range the instrument chose as appropriate for that source level.
This attribute is primarily intended to eliminate the time required by the automatic range selection
performed by a sourcing instrument. Because selecting a fixed range prevents autoranging, an
overrange condition can occur. For example, sourcing 10.0 V on the 2601B-PULSE 6 V range causes
an overrange condition.
Example
smua.source.rangev = 1
Selects the 1 V source range.
Also see
Range (on page 4-54)
reset() (on page 11-156)
setup.recall() (on page 11-175)
smua.measure.rangeY (on page 11-206)
smua.reset() (on page 11-222)
smua.source.autorangeY (on page 11-224)
