Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-36 2601B-PULSE-901-01A April 2020
bufferVar.timestampresolution
This attribute contains the resolution of the timestamp.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Not applicable
See Details
1e-6 (1 µs)
Usage
resolution = bufferVar.timestampresolution
resolution
Timestamp resolution in seconds (minimum 1 µs)
bufferVar
The reading buffer; can be a dynamically allocated user-defined buffer or a dedicated
reading buffer
Details
Assigning a value to this attribute sets the resolution for the timestamps. Reading this attribute returns
the timestamp resolution value. This value can only be changed with an empty buffer. Empty the
buffer using the bufferVar.clear() function.
The finest timestamp resolution is 0.000001 seconds (1 μs). At this resolution, the reading buffer can
store unique timestamps for up to 71 minutes. This value can be increased for very long tests.
The value specified when setting this attribute will be rounded to an even power of 2 µs.
For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the
reading buffer is saved to nonvolatile memory.
Example
smua.nvbuffer1.timestampresolution = 0.000008
Sets the timestamp resolution of
dedicated reading buffer 1 to 8 μs.
Also see
bufferVar.clear() (on page 11-21)
bufferVar.collecttimestamps (on page 11-24)
bufferVar.timestamps (on page 11-37)
Reading buffers (on page 5-1)
smua.measure.overlappedY() (on page 11-205)
smua.measure.Y() (on page 11-209)
smua.nvbufferY (on page 11-211)
smua.trigger.measure.Y() (on page 11-251)
