Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-45
digio.trigger[N].EVENT_ID
This constant identifies the trigger event generated by the digital I/O line N.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Constant
Yes
Usage
eventID = digio.trigger[N].EVENT_ID
eventID
The trigger event number
N
Digital I/O trigger line (1 to 14)
Details
To have another trigger object respond to trigger events generated by the trigger line, set the stimulus
attribute of the other object to the value of this constant.
Example
digio.trigger[5].stimulus = digio.trigger[3].EVENT_ID
Uses a trigger event on digital I/O trigger line 3 to be the stimulus for digital I/O trigger line 5.
Also see
None
digio.trigger[N].mode
This attribute sets the mode in which the trigger event detector and the output trigger generator operate on the
given trigger line.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
Digital I/O trigger N reset
Recall setup
Not saved
0 (digio.TRIG_BYPASS)
Usage
triggerMode = digio.trigger[N].mode
digio.trigger[N].mode = triggerMode
triggerMode
The trigger mode; see Details for values
N
Digital I/O trigger line (1 to 14)
