Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-136 2601B-PULSE-901-01A April 2020
Details
This attribute can be set to initialize the pseudo line state to a known value.
Setting this attribute does not cause the LAN trigger to generate any events or output packets.
Example
print(lan.trigger[1].pseudostate)
Get the present simulated line state for the LAN event 1.
Also see
None
lan.trigger[N].stimulus
This attribute specifies events that cause this trigger to assert.
Instrument reset
LAN trigger N reset
Recall setup
Usage
triggerStimulus = lan.trigger[N].stimulus
lan.trigger[N].stimulus = triggerStimulus
The LAN event identifier used to trigger the event
A number specifying the trigger packet over the LAN for which to set or query the
trigger source (1 to 8)
Details
This attribute specifies which event causes a LAN trigger packet to be sent for this trigger. Set
triggerStimulus to one of the trigger event IDs, which are shown in the following table.
smua.trigger.SWEEPING_EVENT_ID
Occurs when the source-measure unit (SMU) transitions
from the idle state to the arm layer of the trigger model
smua.trigger.ARMED_EVENT_ID
Occurs when the SMU moves from the arm layer to the
trigger layer of the trigger model
smua.trigger.SOURCE_COMPLETE_EVENT_ID
Occurs when the SMU completes a source action
smua.trigger.MEASURE_COMPLETE_EVENT_ID
Occurs when the SMU completes a measurement action
smua.trigger.PULSE_COMPLETE_EVENT_ID
Occurs when the SMU completes a pulse
smua.trigger.SWEEP_COMPLETE_EVENT_ID
Occurs when the SMU completes a sweep
smua.trigger.IDLE_EVENT_ID
Occurs when the SMU returns to the idle state
digio.trigger[N].EVENT_ID
Occurs when an edge is detected on a digital I/O line
tsplink.trigger[N].EVENT_ID
Occurs when an edge is detected on a TSP-Link line
Occurs when the appropriate LXI trigger packet is
received on LAN trigger object N
Occurs when the TRIG key on the front panel is pressed
