Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-132 2601B-PULSE-901-01A April 2020
Details
For TCP connections, this closes the TCP connection.
The LAN trigger automatically disconnects when either the lan.trigger[N].protocol or
lan.trigger[N].ipaddress attributes for this event are changed.
Also see
lan.trigger[N].ipaddress (on page 11-132)
lan.trigger[N].protocol (on page 11-135)
lan.trigger[N].EVENT_ID
This constant is the event identifier used to route the LAN trigger to other subsystems (using stimulus properties).
Type
TSP-Link accessible
Affected by
Where saved
Default value
Constant
Yes
Usage
lan.trigger[N].EVENT_ID
N
The LAN event number (1 to 8)
Details
Set the stimulus of any trigger event detector to the value of this constant to have it respond to
incoming LAN trigger packets.
Example
digio.trigger[14].stimulus = lan.trigger[1].EVENT_ID
Route occurrences of triggers on LAN
trigger 1 to digital I/O trigger 14.
Also see
None
lan.trigger[N].ipaddress
This attribute specifies the address (in dotted-decimal format) of UDP or TCP listeners.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
LAN trigger N reset
Recall setup
Not saved
"0.0.0.0"
Usage
ipAddress = lan.trigger[N].ipaddress
lan.trigger[N].ipaddress = "ipAddress"
ipAddress
The LAN address for this attribute as a string in dotted decimal notation
N
The LAN event number (1 to 8)
