status.questionable.*
These attributes manage the questionable status register set of the status model.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
13,056 (All bits set)
Usage
questionableRegister = status.questionable.condition
questionableRegister = status.questionable.enable
questionableRegister = status.questionable.event
questionableRegister = status.questionable.ntr
questionableRegister = status.questionable.ptr
status.questionable.enable = questionableRegister
status.questionable.ntr = questionableRegister
status.questionable.ptr = questionableRegister
questionableRegister
The status of the questionable status register; a zero (0) indicates
no bits set (also send 0 to clear all bits); other values indicate
various bit settings
Details
These attributes are used to read or write to the questionable status registers. Reading a status
register returns a value. In the binary equivalent, the least significant bit is bit B0, and the most
significant bit is bit B15. For example, if a value of 1.22880e+04 (which is 12,288) is read as the value
of the condition register, the binary equivalent is 0011 0000 0000 0000. This value indicates that bits
B12 and B13 are set.
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
**
>
>
>
>
>
>
>
>
>
>
>
>
>
>
*
0
0
1
1
0
0
0
0
0
0
0
0
0
0
0
0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
Bit
Value and description
B0 to B7
Not used
B8
status.questionable.CALIBRATION
status.questionable.CAL
An enabled bit in the questionable status calibration summary event register is set.
Bit B6 decimal value: 256
