Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-133
Details
Sets the IP address for outgoing trigger events.
Set to "0.0.0.0" for multicast.
After changing this setting, the lan.trigger[N].connect() command must be called before
outgoing messages can be sent.
Example
lan.trigger[3].protocol = lan.TCP
lan.trigger[3].ipaddress = "192.168.1.100"
lan.trigger[3].connect()
Set the protocol for LAN trigger 3 to be
lan.TCP when sending LAN triggers.
Use IP address "192.168.1.100" to
connect the LAN trigger.
Also see
lan.trigger[N].connect() (on page 11-130)
lan.trigger[N].mode
This attribute sets the trigger operation and detection mode of the specified LAN event.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
LAN trigger N reset
Recall setup
Not saved
0 (lan.TRIG_EITHER)
Usage
mode = lan.trigger[N].mode
lan.trigger[N].mode = mode
mode
A number representing the trigger mode (0 to 7); see the Details section for
more information
N
A number representing the LAN event number (1 to 8)
Details
This command controls how the trigger event detector and the output trigger generator operate on the
given trigger. These settings are intended to provide behavior similar to the digital I/O triggers.
LAN trigger mode values
Mode
Number
Trigger packets detected as
input
LAN trigger packet generated
for output with a…
lan.TRIG_EITHER
0
Rising or falling edge (positive
or negative state)
negative state
lan.TRIG_FALLING
1
Falling edge (negative state)
negative state
lan.TRIG_RISING
2
Rising edge (positive state)
positive state
lan.TRIG_RISINGA
3
Rising edge (positive state)
positive state
lan.TRIG_RISINGM
4
Rising edge (positive state)
positive state
lan.TRIG_SYNCHRONOUS
5
Falling edge (negative state)
positive state
lan.TRIG_SYNCHRONOUSA
6
Falling edge (negative state)
positive state
lan.TRIG_SYNCHRONOUSM
7
Rising edge (positive state)
negative state
