Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-129
lan.trigger[N].assert()
This function simulates the occurrence of the trigger and generates the corresponding event ID.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
lan.trigger[N].assert()
N
The LAN event number (1 to 8)
Details
Generates and sends a LAN trigger packet for the LAN event number specified.
Sets the pseudo line state to the appropriate state.
The following indexes provide the listed LXI events:
▪ 1:LAN0
▪ 2:LAN1
▪ 3:LAN2
▪ …
▪ 8:LAN7
Example
lan.trigger[5].assert()
Creates a trigger with LAN packet 5.
Also see
lan.lxidomain (on page 11-119)
lan.trigger[N].clear() (on page 11-129)
lan.trigger[N].mode (on page 11-133)
lan.trigger[N].overrun (on page 11-134)
lan.trigger[N].stimulus (on page 11-136)
lan.trigger[N].wait() (on page 11-137)
Understanding hardware value and pseudo line state (on page 6-21)
lan.trigger[N].clear()
This function clears the event detector for a LAN trigger.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
lan.trigger[N].clear()
N
The LAN event number (1 to 8) to clear
