Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-135
lan.trigger[N].protocol
This attribute sets the LAN protocol to use for sending trigger messages.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
LAN trigger N reset
Recall setup
Not saved
0 (lan.TCP)
Usage
protocol = lan.trigger[N].protocol
lan.trigger[N].protocol = protocol
protocol
The protocol to use for messages from the trigger:
▪ 0 or lan.TCP
▪ 1 or lan.UDP
▪ 2 or lan.MULTICAST
N
The LAN event number (1 to 8)
Details
The LAN trigger listens for trigger messages on all supported protocols, but uses the designated
protocol for sending outgoing messages. After changing this setting, lan.trigger[N].connect()
must be called before outgoing event messages can be sent.
When the lan.MULTICAST protocol is selected, the lan.trigger[N].ipaddress attribute is
ignored and event messages are sent to the multicast address 224.0.23.159.
Example
print(lan.trigger[1].protocol)
Get LAN protocol to use for sending trigger messages for LAN
event 1.
Also see
lan.trigger[N].connect() (on page 11-130)
lan.trigger[N].ipaddress (on page 11-132)
lan.trigger[N].pseudostate
This attribute sets the simulated line state for the LAN trigger.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
LAN trigger N reset
Recall setup
Not saved
1
Usage
pseudostate = lan.trigger[N].pseudostate
lan.trigger[N].pseudostate = pseudostate
pseudostate
The simulated line state (0 or 1)
N
A number representing the LAN event number (1 to 8)
