Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-53
Details
The binary representation of data indicates the output pattern to be written to the I/O port. For
example, a data value of 170 has a binary equivalent of 00000010101010. Lines 2, 4, 6, and 8 are
set high (1), and the other 10 lines are set low (0).
Write-protected lines are not changed.
The reset() function does not affect the present states of the digital I/O lines.
Use the digio.writebit() and digio.writeport() commands to control the output state of
the synchronization line when trigger operation is set to digio.TRIG_BYPASS.
Example
digio.writeport(255)
Sets digital I/O Lines 1 through 8 high (binary
00000011111111).
Also see
digio.readbit() (on page 11-42)
digio.readport() (on page 11-43)
digio.writebit() (on page 11-52)
digio.writeprotect (on page 11-53)
digio.writeprotect
This attribute contains the write-protect mask that protects bits from changes from the digio.writebit() and
digio.writeport() functions.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
Recall setup
Saved setup
0
Usage
mask = digio.writeprotect
digio.writeprotect = mask
mask
Sets the value that specifies the bit pattern for write-protect
Details
Bits that are set to one cause the corresponding line to be write-protected.
The binary equivalent of mask indicates the mask to be set for the I/O port. For example, a mask
value of 7 has a binary equivalent of 00000000000111. This mask write-protects lines 1, 2, and 3.
Example
digio.writeprotect = 15
Write-protects lines 1, 2, 3, and 4.
Also see
digio.writebit() (on page 11-52)
digio.writeport() (on page 11-52)
