Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-68 2601B-PULSE-901-01A April 2020
Key codes
Value
Key list
Value
Key list
65
display.KEY_RANGEUP
85
display.KEY_RECALL
68
display.KEY_MENU
86
display.KEY_MEASA
69
display.KEY_MODEA
87
display.KEY_DIGITSA
70
display.KEY_RELA
88
display.KEY_OUTPUTA
71
display.KEY_RUN
92
display.KEY_TRIG
72
display.KEY_DISPLAY
93
display.KEY_LIMITA
73
display.KEY_AUTO
94
display.KEY_SPEEDA
75
display.KEY_EXIT
95
display.KEY_LOAD
77
display.KEY_FILTERA
97
display.WHEEL_ENTER
78
display.KEY_STORE
103
display.KEY_RIGHT
79
display.KEY_SRCA
104
display.KEY_LEFT
80
display.KEY_CONFIG
107
display.WHEEL_LEFT
81
display.KEY_RANGEDOWN
114
display.WHEEL_RIGHT
82
display.KEY_ENTER
When using this function, send built-in constants, such as display.KEY_RIGHT, rather than the
numeric value, such as 103. This allows for better forward compatibility with firmware revisions.
Example
display.sendkey(display.KEY_RUN)
Simulates pressing the RUN key.
Also see
Front panel (on page 3-1)
display.smua.digits
This attribute sets the front-panel display resolution of the selected measurement.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
Recall setup
Saved setup
5 (display.DIGITS_5_5)
Usage
digits = display.smua.digits
display.smua.digits = digits
digits
Set digits to one of the following values:
▪ Select 4-1/2 digit resolution (4 or display.DIGITS_4_5)
▪ Select 5-1/2 digit resolution (5 or display.DIGITS_5_5)
▪ Select 6-1/2 digit resolution (6 or display.DIGITS_6_5)
Details
This attribute sets the display resolution.
