Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-246 2601B-PULSE-901-01A April 2020
Example
smua.trigger.endpulse.action = smua.SOURCE_IDLE
smua.trigger.endpulse.stimulus = trigger.timer[1].EVENT_ID
Configure the end pulse action to achieve a pulse and select the event, trigger.timer[1].EVENT_ID, that
causes the arm event detector to enter the detected state.
Also see
Triggering (on page 6-1)
smua.trigger.endsweep.action
This attribute sets the action of the source at the end of a sweep.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Not saved
0 (smua.SOURCE_IDLE)
Usage
action = smua.trigger.endsweep.action
smua.trigger.endsweep.action = action
action
The source action at the end of a sweep; set to one of the following values:
▪ 0 or smua.SOURCE_IDLE: Sets the source level to the programmed (idle) level at the
end of the sweep
▪ 1 or smua.SOURCE_HOLD: Sets the source level to stay at the level of the last step
Details
Use this attribute to configure the source action at the end of the sweep. The SMU can be
programmed to return to the idle source level or hold the last value of the sweep.
Example
smua.trigger.endsweep.action = smua.SOURCE_IDLE
Sets SMU return the source back to the idle source level at the end of a sweep.
Also see
Triggering (on page 6-1)
smua.trigger.IDLE_EVENT_ID
This constant contains the idle event number.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Constant
Yes
Usage
eventID = smua.trigger.IDLE_EVENT_ID
eventID
The idle event number
