Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-277
Example 2
status.measurement.voltage_limit.enable = 2
Uses the decimal value to set the SMUA bit, B1, of the measurement event voltage limit summary enable
register.
Also see
Measurement event registers (on page 15-7)
status.node_enable
This attribute stores the system node enable register.
Usage
nodeEnableRegister = status.node_enable
status.node_enable = nodeEnableRegister
The status of the system node enable register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other values
indicate various bit settings
Details
This attribute is used to read or write to the system node enable register. Reading the system node
enable register returns a value. The binary equivalent of the value of this attribute indicates which
register bits are set. In the binary equivalent, the least significant bit is bit B0, and the most significant
bit is bit B7. For example, if a value of 1.29000e+02 (which is 129) is read as the value of this
register, the binary equivalent is 1000 0001. This value indicates that bit B0 and bit B7 are set.
* Least significant bit
** Most significant bit
Assigning a value to this attribute enables one or more status events. When an enabled status event
occurs, a summary bit is set in the appropriate system summary register. The register and bit that is
set depends on the TSP-Link node number assigned to this instrument.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
