Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-273
Example 1
status.measurement.instrument.smua.enable = status.measurement.instrument.smua.VLMT
Uses a constant to set the VLMT bit of the measurement event SMU A summary enable register.
Example 2
status.measurement.instrument.smua.enable = 1
Uses the decimal value to set the VLMT bit of the measurement event SMU A summary enable register.
Also see
Measurement event registers (on page 15-7)
smua.pulser.protect.tripped (on page 11-218)
status.measurement.protection.*
This attribute contains the registers of the measurement event protection summary register set.
Usage
measurementRegister = status.measurement.protection.condition
measurementRegister = status.measurement.protection.enable
measurementRegister = status.measurement.protection.event
measurementRegister = status.measurement.protection.ntr
measurementRegister = status.measurement.protection.ptr
status.measurement.protection.enable = measurementRegister
status.measurement.protection.ntr = measurementRegister
status.measurement.protection.ptr = measurementRegister
The status of the measurement event protection summary
register; a zero (0) indicates no bits set (also send 0 to clear all
bits); other values indicate various bit settings
Details
These attributes are used to read or write to the measurement event protection summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
