Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 15: Status model
2601B-PULSE-901-01A April 2020 15-25
Register programming example
The command sequence below programs the instrument to generate a service request (SRQ) and set
the system summary bit in all TSP-Link nodes when the current limit on channel A is exceeded.
-- Clear all registers.
status.reset()
-- Enable current limit bit in current limit register.
status.measurement.current_limit.enable = status.measurement.current_limit.SMUA
-- Enable status measure current limit bit.
status.measurement.enable = status.measurement.ILMT
-- Set system summary; enable MSB.
status.node_enable = status.MSB
-- Enable status SRQ MSB.
status.request_enable = status.MSB
TSP-Link system status
The TSP-Link
®
expansion interface allows instruments to communicate with each other. The test
system can be expanded to include up to 32 TSP-enabled instruments. In a TSP-Link system, one
node (instrument) is the master and the other nodes are the subordinates. The master can control the
other nodes (subordinates) in the system. See TSP-Link system expansion interface (on page 10-45)
for details about the TSP-Link system.
The system summary registers, shown in the Status byte and service request enable register (on
page 15-5) and the System summary and standard event registers (on page 15-6), are shared by all
nodes in the TSP-Link system. A status event that occurs at a subordinate node can generate an
SRQ (service request) in the master node. After detecting the service request, your program can then
branch to an appropriate subroutine that will service the request. See Status byte and service request
(SRQ) (on page 15-15) for details.
Status model configuration example
In this example, a current limit (compliance) event in node 15 will set the RQS bit of the Status Byte of
the master node. The commands to configure the status model for this example are provided in
Status configuration (enable) commands (on page 15-26).
