Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-302 2601B-PULSE-901-01A April 2020
Bit
Value and description
B0 to B9
Not used
B10
status.operation.instrument.trigger_timer.TRIGGER_OVERRUN
status.operation.instrument.trigger_timer.TRGOVR
Set bit indicates one or more enabled bits for the operation status trigger timer overrun register
is set.
Bit B10 decimal value: 1,024
Binary value:
0100 0000 0000
B11 to B15
Not used
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. For example, to set bit B10, set operationRegister to 1024.
Example
status.operation.instrument.trigger_timer.enable = 1024
Uses the decimal value to set the TRGOVR bit of the operation status trigger timer summary enable register.
Also see
Operation Status Registers (on page 15-8)
status.operation.instrument.trigger_timer.trigger_overrun.* (on page 11-302)
status.operation.instrument.trigger_timer.trigger_overrun.*
This attribute contains the operation status trigger timer overrun register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
510 (All bits set)
Usage
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.condition
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.enable
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.event
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.ntr
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.ptr
status.operation.instrument.trigger_timer.trigger_overrun.enable =
operationRegister
status.operation.instrument.trigger_timer.trigger_overrun.ntr =
operationRegister
status.operation.instrument.trigger_timer.trigger_overrun.ptr =
operationRegister
