Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-276 2601B-PULSE-901-01A April 2020
status.measurement.voltage_limit.*
This attribute contains the measurement event voltage limit summary register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
2 (All bits set)
Usage
measurementRegister = status.measurement.voltage_limit.condition
measurementRegister = status.measurement.voltage_limit.enable
measurementRegister = status.measurement.voltage_limit.event
measurementRegister = status.measurement.voltage_limit.ntr
measurementRegister = status.measurement.voltage_limit.ptr
status.measurement.voltage_limit.enable = measurementRegister
status.measurement.voltage_limit.ntr = measurementRegister
status.measurement.voltage_limit.ptr = measurementRegister
measurementRegister
The status of the measurement voltage limit summary register; a
zero (0) indicates no bits set (also send 0 to clear all bits); other
decimal values indicate various bit settings
Details
These attributes read or write to the measurement event voltage limit summary registers. Reading a
status register returns a value. The binary equivalent of the returned value indicates which register
bits are set. The least significant bit of the binary number is bit B0, and the most significant bit is bit
B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
Bit
Value and description
B0
Not used
B1
status.measurement.voltage_limit.SMUA
Set bit indicates the enabled VLMT bit for the SMU A measurement register is set.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2 to B15
Not used
In addition to the above constants, measurementRegister can be set to the decimal value of the
bit to set.
Example 1
status.measurement.voltage_limit.enable = status.measurement.voltage_limit.SMUA
Uses the constant to set the SMUA bit, B1, of the measurement event voltage limit summary enable register.
