Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-223
smua.sense
This attribute contains the state of the sense mode.
SMU reset
Instrument reset
Recall setup
Usage
senseMode = smua.sense
smua.sense = senseMode
The sense mode; set to one of the following:
â–ª 0 or smua.SENSE_LOCAL: Selects local sense (2-wire)
â–ª 1 or smua.SENSE_REMOTE: Selects remote sense (4-wire)
â–ª 3 or smua.SENSE_CALA: Selects calibration sense mode
Details
You can do source-measure operations using either 2-wire local sense connections or 4-wire remote
sense connections.
When the pulser is enabled, the instrument always uses 4-wire remote sensing. The setting of
smua.sense is ignored.
You can change the sense mode between local and remote while the output is on.
The smua.SENSE_CALA mode is only used for calibration and may only be selected when calibration
is enabled. The calibration sense mode cannot be selected while the output is on.
Example
smua.sense = smua.SENSE_REMOTE
Select 4-wire remote sensing.
Also see
2-wire local sensing connections (on page 4-10)
4-wire remote sensing connections (on page 4-10)
Sense mode selection (on page 4-25)
