Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-323
Bit
Value
B0
Not used
B1
status.questionable.over_temperature.SMUA
Set bit indicates that an over temperature condition was detected on SMU A.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2 to B15
Not used
As an example, to set bit B1 of the questionable status over temperature summary enable register,
set status.questionable.instrument.enable =
status.questionable.instrument.SMUA. You can also set the bit to its decimal value.
Example
status.questionable.over_temperature.enable =
status.questionable.over_temperature.SMUA
Uses the constant to set the SMU A over temperature summary enable bit of the questionable status register.
Also see
Questionable Status Registers (on page 15-13)
status.questionable.* (on page 11-316)
status.questionable.unstable_output.*
This attribute contains the questionable status unstable output summary register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
2 (All bits set)
Usage
questionableRegister = status.questionable.unstable_output.condition
questionableRegister = status.questionable.unstable_output.enable
questionableRegister = status.questionable.unstable_output.event
questionableRegister = status.questionable.unstable_output.ntr
questionableRegister = status.questionable.unstable_output.ptr
status.questionable.unstable_output.enable = questionableRegister
status.questionable.unstable_output.ntr = questionableRegister
status.questionable.unstable_output.ptr = questionableRegister
operationRegister
The status of the questionable status unstable output summary
register; a zero (0) indicates no bits set (also send 0 to clear all
bits); the only other valid value is 2
