Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-284 2601B-PULSE-901-01A April 2020
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
Bit
Value and description
B0
Not used
B1
status.operation.calibrating.SMUA
Set bit indicates that SMU A is unlocked for calibration.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2 to B15
Not used
Example 1
status.operation.calibrating.enable = status.operation.calibrating.SMUA
Sets the SMUA bit, B1, of the operation status calibration summary enable register using a constant.
Example 2
status.operation.calibrating.enable = 2
Sets the SMUA bit, B1, of the operation status calibration summary enable register using a decimal value.
Also see
Operation Status Registers (on page 15-8)
status.operation.* (on page 11-281)
status.operation.instrument.*
This attribute contains the operation status instrument summary register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
31,746 (All bits set)
Usage
operationRegister = status.operation.instrument.condition
operationRegister = status.operation.instrument.enable
operationRegister = status.operation.instrument.event
operationRegister = status.operation.instrument.ntr
operationRegister = status.operation.instrument.ptr
status.operation.instrument.enable = operationRegister
status.operation.instrument.ntr = operationRegister
status.operation.instrument.ptr = operationRegister
operationRegister
The status of the operation event register; a zero (0) indicates no bits set (also send
0 to clear all bits); other values indicate various bit settings
