Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-285
Details
These attributes are used to read or write to the operation status instrument summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15. For example, if a value of 1.02600e+03 (which is 1,026) is read as the value of the
condition register, the binary equivalent is 0000 0100 0000 0010. This value indicates that bit B1 and
bit B10 are set.
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
**
>
>
>
>
>
>
>
>
>
>
>
>
>
>
*
0
0
0
0
0
1
0
0
0
0
0
0
0
0
1
0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
Bit
Value and description
B0
Not used
B1
status.operation.instrument.SMUA
Set bit indicates one or more enabled bits for the operation status SMU A summary register is set.
Bit B1 decimal value: 2
B2 to B9
Not used
B10
status.operation.instrument.TRIGGER_BLENDER
status.operation.instrument.TRGBLND
Set bit indicates one or more enabled bits for the operation status trigger blender summary
register is set.
Bit B10 decimal value: 1,024.
B11
status.operation.instrument.TRIGGER_TIMER
status.operation.instrument.TRGTMR
Set bit indicates one or more enabled bits for the operation status trigger timer summary register
is set.
Bit B11 decimal value: 2,048
B12
status.operation.instrument.DIGITAL_IO
status.operation.instrument.DIGIO
Set bit indicates one or more enabled bits for the operation status digital I/O summary register is
set.
Bit B12 decimal value: 4,096
B13
status.operation.instrument.TSPLINK
Set bit indicates one or more enabled bits for the operation status TSP-Link summary register is
set.
Bit B13 decimal value: 8,192
B14
status.operation.instrument.LAN
Set bit indicates one or more enabled bits for the operation status LAN summary register is set.
Bit B14 decimal value: 16,384
B15
Not used
As an example, to set bit B1 of the operation status instrument summary enable register, set
status.operation.instrument.enable = status.operation.instrument.SMUA.
