Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-282 2601B-PULSE-901-01A April 2020
Bit
Value and description
B3
status.operation.SWEEPING
status.operation.SWE
Set bit indicates that the summary bit from the status.operation.sweeping register is set.
Bit B3 decimal value: 8
B4
status.operation.MEASURING
status.operation.MEAS
Set bit indicates that the summary bit of the status.operation.measuring register is set.
Bit B4 decimal value: 16
B5 to B9
Not used
B10
status.operation.TRIGGER_OVERRUN
status.operation.TRGOVR
Set bit indicates that the summary bit from the status.operation.trigger_overrun
register is set.
Bit B10 decimal value: 1,024
B11
status.operation.REMOTE_SUMMARY
status.operation.REM
Set bit indicates that the summary bit of the status.operation.remote register is set.
Bit B11 decimal value: 2,048
B12
status.operation.USER
Set bit indicates that the summary bit from the status.operation.user register is set.
Bit B12 decimal value: 4,096
B13
status.operation.INSTRUMENT_SUMMARY
status.operation.INST
Set bit indicates that the summary bit from the status.operation.instrument register is
set.
Bit B13 decimal value: 8,192
B14
status.operation.PROGRAM_RUNNING
status.operation.PROG
Set bit indicates that a command or program is running.
Bit B14 decimal value: 16,384
B15
Not used
As an example, to set bit B12 of the operation status enable register, set
status.operation.enable = status.operation.USER.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B12 and B14, set operationRegister to 20,480 (which
is the sum of 4,096 + 16,384).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
