Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-339
Bit
Value
Decimal value
B6
status.system4.NODE48
64
B7
status.system4.NODE49
128
B8
status.system4.NODE50
256
B9
status.system4.NODE51
512
B10
status.system4.NODE52
1,024
B11
status.system4.NODE53
2,048
B12
status.system4.NODE54
4,096
B13
status.system4.NODE55
8,192
B14
status.system4.NODE56
16,384
B15
Not used
Not applicable
As an example, to set bit B0 of the system summary 4 enable register, set
status.system4.enable = status.system4.enable.EXT.
In addition to the above constants, enableRegister can be set to the decimal value of the bit to
set. To set more than one bit of the register, set enableRegister to the sum of their decimal
values. For example, to set bits B11 and B14, set enableRegister to 18,432 (which is the sum of
2,048 + 16,384).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
enableRegister = status.system4.NODE53 + status.system4.NODE56
status.system2.enable = enableRegister
Uses constants to set bit B11 and bit B14 of the system summary 4 enable register.
Example 2
-- decimal 18432 = binary 0100 1000 0000 0000
enableRegister = 18432
status.system4.enable = enableRegister
Uses a decimal value to set bit B11 and bit B14 of the system summary 4 enable register.
Also see
status.system3.* (on page 11-335)
status.system5.* (on page 11-340)
System summary and standard event registers (on page 15-6)
