Details
These attributes are used to read or write to the operation status trigger overrun summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15. For example, if a value of 1.02600e+03 (which is 1,026) is read as the value of the
condition register, the binary equivalent is 0000 0100 0000 0010. This value indicates that bit B1 and
bit B10 are set.
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
**
>
>
>
>
>
>
>
>
>
>
>
>
>
>
*
0
0
0
0
0
1
0
0
0
0
0
0
0
0
1
0
* Least significant bit
** Most significant bit
The bits in this register summarize events in other registers. A set bit in this summary register
indicates that an enabled event in one of the summarized registers is set.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
Bit
Value and description
B0
Not used
B1
status.operation.trigger_overrun.SMUA
Set bit indicates one of the enabled bits in the operation status SMU A trigger overrun event
register is set.
Bit B1 decimal value: 2
B2 to B9
Not used
B10
status.operation.trigger_overrun.TRIGGER_BLENDER
status.operation.trigger_overrun.TRGBLND
Set bit indicates one of the enabled bits in the operation status trigger blender overrun event
register is set.
Bit B10 decimal value: 1,024
B11
status.operation.trigger_overrun.TRIGGER_TIMER
status.operation.trigger_overrun.TRGTMR
Set bit indicates one of the enabled bits in the operation status trigger timer overrun event register
is set.
Bit B11 decimal value: 2,048
B12
status.operation.trigger_overrun.DIGITAL_IO
status.operation.trigger_overrun.DIGIO
Set bit indicates one of the enabled bits in the operation status digital I/O overrun event register is
set.
Bit B12 decimal value: 4,096
B13
status.operation.trigger_overrun.TSPLINK
Set bit indicates one of the enabled bits in the operation status TSP-Link overrun event register
is set.
Bit B13 decimal value: 8,192
B14
status.operation.trigger_overrun.LAN
Set bit indicates one of the enabled bits in the operation status LAN trigger overrun event register
is set.
Bit B14 decimal value: 16,384
B15
Not used
