Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-289
Bit
Value
Decimal value
B2
status.operation.instrument.digio.trigger_overrun.LINE2
4
B3
status.operation.instrument.digio.trigger_overrun.LINE3
8
B4
status.operation.instrument.digio.trigger_overrun.LINE4
16
B5
status.operation.instrument.digio.trigger_overrun.LINE5
32
B6
status.operation.instrument.digio.trigger_overrun.LINE6
64
B7
status.operation.instrument.digio.trigger_overrun.LINE7
128
B8
status.operation.instrument.digio.trigger_overrun.LINE8
256
B9
status.operation.instrument.digio.trigger_overrun.LINE9
512
B10
status.operation.instrument.digio.trigger_overrun.LINE10
1,024
B11
status.operation.instrument.digio.trigger_overrun.LINE11
2,048
B12
status.operation.instrument.digio.trigger_overrun.LINE12
4,096
B13
status.operation.instrument.digio.trigger_overrun.LINE13
8,192
B14
status.operation.instrument.digio.trigger_overrun.LINE14
16,384
B15
Not used
Not applicable
As an example, to set bit B1 of the operation status digital I/O overrun enable register, set
status.operation.instrument.digio.trigger_overrun.enable =
status.operation.instrument.digio.trigger_overrun.LINE1.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal values. For example, to set bits B1 and B10, set operationRegister to 1,026 (which is
the sum of 2 + 1,024).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
operationRegister = status.operation.instrument.digio.trigger_overrun.LINE1 +
status.operation.instrument.digio.trigger_overrun.LINE10
status.operation.instrument.digio.trigger_overrun.enable = operationRegister
Uses constants to set bit B1 and bit B10 of the operation status digital I/O overrun enable register.
Example 2
operationRegister = 1026
status.operation.instrument.digio.trigger_overrun.enable = operationRegister
Uses the decimal value to set bit B1 and bit B10 of the operation status digital I/O overrun enable register.
