Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-314 2601B-PULSE-901-01A April 2020
Usage
operationRegister = status.operation.user.condition
operationRegister = status.operation.user.enable
operationRegister = status.operation.user.event
operationRegister = status.operation.user.ntr
operationRegister = status.operation.user.ptr
status.operation.user.condition = operationRegister
status.operation.user.enable = operationRegister
status.operation.user.ntr = operationRegister
status.operation.user.ptr = operationRegister
operationRegister
The status of the operation status user register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other values
indicate various bit settings
Details
These attributes are used to read or write to the operation status user registers. Reading a status
register returns a value. The binary equivalent of the value indicates which register bits are set. In the
binary equivalent, the least significant bit is bit B0, and the most significant bit is bit B15. For example,
if a value of 1.29000e+02 (which is 129) is read as the value of the condition register, the binary
equivalent is 0000 0000 1000 0001. This value indicates that bits B0 and B7 are set.
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
**
>
>
>
>
>
>
>
>
>
>
>
>
>
>
*
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
1
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
Bit
Value
Decimal value
B0
status.operation.user.BIT0
1
B1
status.operation.user.BIT1
2
B2
status.operation.user.BIT2
4
B3
status.operation.user.BIT3
8
B4
status.operation.user.BIT4
16
B5
status.operation.user.BIT5
32
B6
status.operation.user.BIT6
64
B7
status.operation.user.BIT7
128
B8
status.operation.user.BIT8
256
B9
status.operation.user.BIT9
512
B10
status.operation.user.BIT10
1,024
B11
status.operation.user.BIT11
2,048
B12
status.operation.user.BIT12
4,096
B13
status.operation.user.BIT13
8,192
