Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 13: Calibration
2601B-PULSE-901-01A April 2020 13-25
Command
Description
smua.source.calibratev(range,
cp1Expected, cp1Reference,
cp2Expected, cp2Reference)
Adjusts the voltage source range*:
±range (source range to adjust).
cp1Expected (source value programmed for point 1).
cp1Reference (reference measurement for point 1).
cp2Expected (source value programmed for point 2).
cp2Reference (reference measurement for point 2).
smua.contact.calibratelo(
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
Adjusts the low/sense low contact check measurement.
cp1Measured (value measured by the SMU for point 1).
cp1Reference (the reference measurement for
point 1).
cp2Measured (value measured by SMU for point 2).
cp2Reference (reference measurement for point 2).
smua.contact.calibratehi(
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
Adjusts the high/sense high contact check measurement.
cp1Measured (value measured by SMU for point 1).
cp1Reference (reference measurement for point 1).
cp2Measured (value measured by SMU for point 2).
cp2Reference (reference measurement for point 2).
smua.pulser.source.calibratebiasi(
range, cp1Expected, cp1Reference,
cp2Expected, cp2Reference)
Adjusts the new bias source calibration constants for the
pulser.
range (pulse current range to adjust).
cp1Expected (source value set for point 1).
cp1Reference (reference measurement for point 1).
cp2Expected (source value set for point 2).
cp2Reference (reference measurement for point 2).
smua.pulser.source.calibratei(
range, cp1Expected, cp1Reference,
cp2Expected, cp2Reference)
Adjusts the current source calibration constants for
the pulser.
range (pulse current range to adjust).
cp1Expected (source value set for point 1).
cp1Reference (reference measurement for point 1).
cp2Expected (source value set for point 2).
cp2Reference (reference measurement for point 2).
smua.pulser.measure.calibratei(range,
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
Adjusts the current measurement calibration constants
for the pulser.
±range (measurement range to adjust).
cp1Measured (2601B-PULSE measured value for
point 1).
cp1Reference (reference measurement for point 1).
cp2Measured (2601B-PULSE measured value for
point 2).
cp2Reference (reference measurement for point 2).
smua.pulser.measure.calibratev(range,
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
Adjusts the voltage measurement calibration constants
for the pulser.
±range (measurement range to adjust).
cp1Measured (2601B-PULSE measured value for
point 1).
cp1Reference (reference measurement for point 1).
cp2Measured (2601B-PULSE measured value for
point 2).
cp2Reference (reference measurement for point 2).
* Point 1 should be performed at approximately 0% of range; point 2 should be performed at approximately
90% of range. See Step sequence (on page 13-22) for points.
