Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 3-35
Error Messages and Codes
Other Verify Flash Error
Error 016-502
Restart Printer
<Download Error>
An error was detected at Flash
memory verify.
page 3-114
Other Out of Memory
Error 016-718
Add Memory
Press OK Button
<Memory Overflow>
Print job data exceeded
memory capacity.
page 3-115
Other Out of Memory
Error 016-718
Job too Large
Press OK Button
<Memory Overflow>
Print job data exceeded
memory capacity.
page 3-115
Other PDL Error
Error 016-720
Press OK Button
<PDL Error>
PDL error occurs.
page 3-115
Other Format Error
Error 016-737
Press OK Button
<Download Format Error>
The download file is broken, or
communication error
detected.
page 3-94
Other Protection Error
Error 016-741
Press OK Button
<Download Error>
The download file is broken, or
communication error
detected.
page 3-94
Other Invalid IDError
Error 016-742
Press OK Button
<Download ID Error>
The download file of other
models (different ID) is
detected.
page 3-94
Other Range Chk Error
Error 016-743
Press OK Button
<Download Range Error>
Due to the wrong data
downloaded, writing was
attempted to the
nonmodifiable area.
page 3-94
Other Check Sum Error
Error 016-744
Press OK Button
<Download Checksum Error>
The download file is broken, or
communication error
detected..
page 3-94
Other Header Error
Error 016-745
Press OK Button
<Download Header Error>
The download file is broken, or
communication error
detected..
page 3-94
Other Invalid User
Error 016-757
Press OK Button
<Auditron-Invalid User>
Account error occurs.
page 3-86
Other Disabled Func
Error 016-758
Press OK Button
<Auditron-Disabled Function>
Disabled function is selected.
page 3-86
Error Message Summary (continued)
System Error Message Error Type Go to

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
