Phaser 6128MFP Service Manual 6-9
Adjustments and Calibrations
Parameter Settings
Print Parameter Setting
This function reads/writes the parameter values, errors, and life counter values
stored in the printer.
Note
Print the parameter list from Service Mode > Parameter > Print before
changing the registration value. The parameter list contains the parameter
and life counter values currently stored in the engine.
To access the Parameter list:
1. Turn the printer power Off (if the printer is On).
2. Simultaneously press the Up Arrow and Down Arrow buttons and turn on the
printer.
3. The Service Mode menu is displayed.
4. Press the Up Arrow or Down Arrow button to find Parameter. Press the OK
button.
5. Select the appropriate item to change (i.e., Slow Scan KtoP). Press the OK
button.
6. Enter the appropriate range using the Up Arrow or Down Arrow button. Press
the OK button.
7. The new value “# *” is displayed.
Note
“*” = data has been saved
8. Press the Stop button to return to the Parameter menu.
Printer Diag Parameter Settings
Item Range Description
Slow Scan K to P
(Shifts 0.17mm/1count)
-128 to 127 Sets the registration in the paper
feeding direction
Slow Scan 600 M,Y,C
(Shifts 0.042mm/1count)
Fast Scan K to M,Y or C
(Shifts 0.042mm/1count)
-128 to 127 Sets the registration in the scanning
direction. Color registration
adjustment Calculation of adjustment
is shown below. (exp. Yellow)
(Value of Fast Scan K to Y + Value of
Fast Scan 2 K to Y )/4
Fast Scan M-Feed ,Tray
(Shifts 0.17mm/1count)
-30 to 30
Fast Scan 2 K to M,Y or C
(Shifts 0.01mm/1count)
-1 to 2
