Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual A-7
Reference
Acronyms and Abbreviations
Acronym Description
A3 Paper size 297 millimeters (11.69 inches) x 420
millimeters (16.54 inches).
A4 Paper size 210 millimeters (8.27 inches) x 297
millimeters (11.69 inches).
A5 Paper size 148 millimeters (5.82 inches) x 210
millimeters (2.10 inches).
AC Alternating Current is type of current available at
power source for the printer.
ADC Automatic Density Control
AMPV Average Monthly Print Volume
APC Auto Power Control
ASSY Assembly
ATM Adobe Type Manager
BCR Bias Charge Roller
BOOTP Boot Parameter Protocol
BTR Bias Transfer Roller
CCD Charge Coupled Device (Photoelectric Converter)
CCW Counter-Clock Wise
CMYK Toner colors for the printer:
Y=yellow, C=cyan, M=magenta, K=black
CRU Customer Replaceable Unit
CRUM Customer Replaceable Unit Meter/Memory
CST Cassette
dB Decibel
DC Direct Current
DDNS Dynamic Domain Name System
DDR2 DIMM Double Data Rate Dual In-Line Memory Module
DEV Developer
DHCP Dynamic Host Configuration Protocol
DPI Dots Per Inch
DRV Drive
DUP Duplex
Duplex 2-sided printing
EA Emulsion Aggregation (Toner)
EEPROM Electrically Erasable Programmable Read-Only
Memory

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
