Phaser 6128MFP Service Manual I – 1
Index
A
abbreviation
error message
, 3-5
AC power
troubleshooting, 4-63
ADC Sensor
control function
, 2-35
description
, 2-22
ADF
board
, 2-53
Motor
location
, 2-54
operation
, 2-54
process diagram
, 2-56
Open Sensor
, 2-49
adjustments
color registration, 6-2
resetting Fuser life counter
, 6-5
setting Fax/Scanner parameter
, 6-11
setting parameter
, 6-9
AMPV
, 1-11
B
Bias Charge Roller (BCR), 2-4
Bias Transfer Roller (BTR)
, 2-9
black and white mode
, 2-39
boot controller, firmware update
, A-10
button functions, control panel
, 1-7
C
calibrations
initializing NVM
, 6-6
initializing print meter
, 6-6
scanner
, 6-7
chain link code
control panel message, 3-6
cleaning
tools
, 7-2
Clutch
Registration, 2-19
collation
, 1-23
color mode switching
, 2-28
color registration
, 2-35
adjustment
, 6-2
adjustments
auto adjustment
, 6-3
disabling
, 6-3
enabling
, 6-3
manual adjustment
, 6-4
configuration page
, 1-27
consumables
Print Cartridge
troubleshooting
, 3-66
Toner Cartridge
part number
, 9-34
Control Panel
buttons, 1-7
LED states
, 1-9
shortcuts
, 1-9
troubleshooting
, 4-52
controller functions
, 1-23
information pages
, 1-27
job control
, 1-23
maintenance function
, 1-26
non-genuine mode
, 1-25
copy
specifications
, 1-13
counters
billing print
, 1-25
Cover
left side, removal, 8-17
rear, removal
, 8-22
top, removal
, 8-25
covers
removal, 8-15
CRUM Connector
location, 2-25
operation
, 2-25
D
DC power
troubleshooting
, 4-64
Diagnostic Tests
Exit Mode
, 4-32
Installation
, 4-28
Parameter
, 4-31
Print Info
, 4-27
Test Print
, 4-30
disassembly
covers
, 8-15
paper feeder
, 8-27
Xerographics
, 8-86
Dispenser
location, 2-25
operation
, 2-25
Drive
black and white mode, 2-39
color mode switching
, 2-28
components
, 2-27
development
, 2-43
excess toner collection
, 2-43
Feed Drive location
, 2-27
Feed Drive operation
, 2-27
K mode
, 2-39
Main Drive location
, 2-27
Main Drive operation
, 2-27, 2-37
