I – 2 Phaser 6128MFP Service Manual
Sub Drive, 2-39
Sub Drive location
, 2-27
Sub Drive operation
, 2-27
Drive Clutch Kit
removal
, 8-35
E
EEPROM Board
location
, 2-29
operation
, 2-31
electrical
data flow diagram
, 2-32
specifications
, 1-15
electrostatic discharge (ESD)
, 3-xvii
End Guide, Paper Tray
location
, 2-14
operation
, 2-14
engine test print
, 4-62
envelopes
supported sizes, 1-22
environmental specifications
, 1-16
Erase Lamp
operation, 2-26
removal, LED assembly
, 8-86
troubleshooting, black
, 4-50
troubleshooting, YMC
, 4-51
error history report
accessing
, 3-2
chain link code
, 3-2
paper jam history
, 3-2, 3-3
system fail history
, 3-3
error message
abbreviation, 3-5
error messages
POST, 4-3
European Union
, 3-xxi
excess toner
, 2-43
Exit Roller
location, 2-22
Exit Sensor
location, 2-22
operation
, 2-23
troubleshooting
, 4-33
F
Fan
location
, 2-29
Main Fan
Motor error, 3-103
operation
, 2-29
fasteners
precautions, 8-6
screws
, 8-6
Fax
color fax troubleshooting, 4-60
operation
, 2-58
Protocol Monitor
, 2-61
specifications
, 1-14
standards
, 2-65
Feed Drive Assembly
removal, 8-37
Feed Roller
operation, 2-17
removal
, 8-10
Feed Solenoid
operation, 2-17
removal
, 8-34
Feeder Assembly
removal, 8-75
firmware update
, 1-26
boot controller
, A-10
controller
, A-11
MPC
, A-12
first print output time (FPOT)
, 1-18
FPOT
, 1-18
Front Cover
troubleshooting
, 3-105
Fuser
components
, 2-23
cooling down
, 2-36
Exit Sensor
, 2-23
operation
, 2-23
resetting life counter
, 6-5
temperature control
, 2-36
warming-up
, 2-37
G
GFI Breaker, 2-32
H
Humidity Sensor
location
, 2-29
operation
, 2-31
removal
, 8-45
troubleshooting
, 3-113
HVPS
location, 2-29
operation
, 2-30
I
Image Processor Board
location
, 2-29, 2-31
operation
, 2-31
removal
, 8-41
Imaging Unit
removal
, 8-8
Information pages
configuration, 1-27
error history
, 1-29
job history
, 1-28
PCL fonts
, 1-28
