Xerox Phaser 6128MFP - Reseat Fuser Error

3-56 Phaser 6128MFP Service Manual
Error Messages and Codes
Reseat Fuser Error
Warning
Allow the Fuser to cool before removal.
The Fuser has failed. This troubleshooting procedure applies to this error.
Applicable Error
• 010-317: ReseatFuser
Initial Actions
• Ensure that the Fuser latches are fully locked.
• Cycle printer power.
• If problem persists, follow the procedure below.
4 Replace the Fuser (page 8-11).
Does the error persist?
NOTE
Reset the Fuser life counter after
installation of a new Fuser.
Go to step 5. Complete.
5 Replace the LVPS (page 8-47).
Does the error persist?
Replace the
MCU Board
(page 8-57).
Complete.
Troubleshooting References
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser, PL6.1.1
■ MCU Board, PL10.7.7
■ Fuser Harness, PL10.8.6
■ “Map 4 - Imaging” on page 10-9
■ “Fuser” on page 10-21
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the connectors P/J17 and P/J171
between the MCU Board and the Fuser.
Are the connectors secure?
Go to step 2. Reconnect
the
connectors.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
