Xerox Phaser 6128MFP - Reseat Paper at Manual Feed

Phaser 6128MFP Service Manual 3-83
Error Messages and Codes
Reseat Paper at Manual Feed
The Manual Feed No Paper Sensor did not detect media within the specified time.
The following troubleshooting procedure applies to this error.
Applicable Error
• Reseat Paper at Manual Feeed Slot
Initial Actions
• Check the media path for obstructions or debris.
• Check manual feed guide adjustment.
• Check that the media required by the print job is the type/size loaded.
• Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Registration Roller Actuator, PL3.3.8
■ Registration Sensor, PL3.2.13
■ Manual Feed Actuator, PL3.2.14
■ Main Drive Assembly, PL7.1.2
■ Feed Drive Assembly, PL7.1.4
■ Left Side Harness, PL10.4.18
■ MCU Board, PL10.7.7
■ Main Motor Harness, PL10.8.7
■ Registration (KSNR) Harness, PL10.8.9
■ “Map 2 - Feed and Laser Unit” on page 10-7
■ “Media Feed” on page 10-15
■ “Main Drive” on page 10-16
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the media size.
Does media size match the print
job?
Replace the
media.
Go to step 2.
2 Check the Front Cover latch.
Does the Front Cover latch correctly?
Go to step 3. Repair or
replace the
Front Cover
(page 8-15).
3 Run the Main Motor test (DO-0) on
(page 4-41).
Does the motor and Registration
Rollers rotate?
Go to step 4. Repair or
replace the
Main Drive
Assembly
(page 8-58).
