Phaser 6128MFP Service Manual 8-7
Service Parts Disassembly
Maintenance Items and Consumables
Maintenance items include the Separator Roller in the Paper Tray, Imaging Unit,
and Fuser. Consumables consist of the four Toner Cartridges.
Separator Roller
PL10.3.5
1. Hold the tray and pinch the left and right hooks of the Separator Roller. Swing
the Separator Roller to release the two hooks.
2. Pull the Separator Roller up to remove it from the Tray.
s6128mfp-177
s6128mfp-178
