Xerox Phaser 6128MFP Service Manual

1-14 Phaser 6128MFP Service Manual
General Information
Fax Specifications
Fax Specifications
Characteristic Specifications
Communication
Mode
■ Priority 1: ITU-T Super G3
■ Priority 2: ITU-T G3 ECM
■ Priority 3: ITU-T G3
Resolution
Lines:
Pixels
B&W (Fast Scan x Slow Scan)
■ 8 pixels x 3.85 line / mm
■ 8 pixels x 7.7 line / mm
■ 8 pixels x 15.4 line / mm
■ 16 pixels x 15.4 line /mm
■ 400 x 400 ppi / 25mm
■ 300 x 300 ppi / 25mm
■ 200 x 200 ppi / 25mm
■ 100 x 100 ppi / 25mm
Supported Protocols
■ V. 34 (Max.33.6 kbps)
■ V. 17 (14.4/12/9.6/7.2 kbps)
■ V. 29 (9.6/7.2 kbps)
■ V. 27ter (4.8/2.4 kbps)
Compression
Format
MH, MR, MMR, JBIG (B&W 1-bit)
JPEG (Color Fax)
Incoming Call
Control
Telephone Mode, Fax Mode, Telephone/ Fax Mode,
Answering Machine Mode, Distinctive Ring Pattern
Detection (DRPD)
Lighter/Darker 7 levels
DM Protection Reject junk Fax
Forwarding & Local
Print
Supported
Color Fax Resolution is fixed by 200 x 200 dpi
Fax Address Book Up to 200 Speed Dial numbers and up to 6 Group Dial
numbers stored in device memory. The Group Dial
Numbers may have up to 200 fax numbers associated
with each group; however, the total number of allowable
fax numbers for all groups is 200.
Lan Fax
Resolution Normal: 200 x 100 dpi
Fine: 200 x 200 dpi
Super Fine: 400 x 400 dpi
Driver PCL driver - supported
PS driver - not support
Color Not support
Delayed Start Up to 24 hours
Broadcast Sending Up to 30 destinations
Zoom 25%-400% (same as printer driver)

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
