2-12 Phaser 6128MFP Service Manual
Theory of Operation
Media Path
Media Path
Media is supplied from the Tray or the manual feed slot, and is transported into the
printer along the paper path as shown in the diagram.
s6128-012
Manual Feed Slot
Tray
Multiple Sheet
Feed Prevention
Motor Drive/
Solenoid/Feed Roller
Leading Edge
Registration
(Except SSI)
Registration Assembly
Transfer Belt
Fuser
Exit Roller in the Fuser
Top Cover
Motor Drive/Clutch/
Registration Roller
Motor Drive/Belt
Motor Drive/Heat Roller/
Pressure Belt
