Xerox Phaser 6128MFP Service Manual

3-6 Phaser 6128MFP Service Manual
Error Messages and Codes
Error Message and Code Summary
The Error Message Summary table lists possible errors, along with the
corresponding code, and page reference for the corrective procedure.
• The System column lists the sub-system reporting the error.
• The Error Message column shows the message as it appears on the display
when the error occurs during normal operation.
• The Error Type lists the fault trigger responsible for the error.
• The Go to column references the procedure related to the error.
Use this table to identify the proper procedure to correct the reported error.
Error Message Summary
System Error Message Error Type Go to
FAX
Controller
MFD Memory Full
Error 017-970
Press OK Button
<Out of Memory>
Out of Memory for AIOC
page 3-133
FAX
Controller
MFD Controller Error
Error 017-971
Press OK Button
<FlashROM Write Error>
Write error at Image Data
FlashROM.
page 3-135
FAX
Controller
MFD Controller Error
Error 017-972
Press OK Button
<FlashROM Erase Error>
Erase error at Image Data
FlashROM.
page 3-135
FAX
Controller
MFD Controller Error
Error 017-973
Press OK Button
<FlashROM Suspend Error>
Suspend error at Image Data
FlashROM.
page 3-135
FAX
Controller
MFD Controller Error
Error 017-974
Press OK Button
<FlashROM Resume Error>
Resume error at Image Data
FlashROM.
page 3-135
FAX
Controller
MFD Controller Error
Error 017-975
Press OK Button
<File Error>
File Handle Count exceeds
Limit.
page 3-135
FAX
Controller
MFD Controller Error
Error 017-976
Press OK Button
<File Error>
File Count exceeds
Manageable Limit.
page 3-135
FAX
Controller
MFD Controller Error
Error 017-977
Press OK Button
<File Error>
Document Count exceeds
Manageable Limit.
page 3-135
FAX
Controller
MFD Controller Error
Error 017-978
Press OK Button
<File Error>
Document Page Count
exceeds Limit.
page 3-135
FAX
Controller
MFD Controller Error
Error 017-979
Press OK Button
<File Error>
File Double Open.
page 3-135

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
